Color

Application of the color palette brings a unified and recognizable consistency to the array of digital products and interfaces.

Overview

https://carbondesignsystem.com/4aac660a6246f8324e2c4dd8d47f4fa5/introduction.gif — Carbon Design Colors Overview

Color Anatomy

Carbon’s default themes are derived from the IBM Design Language color palette. The neutral gray family is dominant in the default themes, making use of subtle shifts in value to organize content into distinct zones.

The core blue family serves as the primary action color. Additional colors are used sparingly and purposefully.

See also

Color overview - Carbon Docs

Tokens

Tokens are a method of applying color in a consistent, reusable, and scalable way. They are used in place of hard coded values, like hex codes. Whenever you update the theme of your app, these color tokens attains the desired value based on the current color theme and all the visual elements are updated dynamically.

For a complete list of available color tokens see the below API documentation of the available color classes implementing the colors or run the example code given below. You can also visit the official Carbon docs for reference.

See also

Color tokens - Carbon Docs

Example

from kivy.clock import Clock
from kivy.core.window import Window


def set_softinput(*args) -> None:
    Window.keyboard_anim_args = {"d": 0.2, "t": "in_out_expo"}
    Window.softinput_mode = "below_target"


Window.on_restore(Clock.schedule_once(set_softinput, 0.1))

appkv = """
CScreen:
    ColorView:
        size_hint: 1, 1
        viewclass: "MyColor"
        bar_width: "20dp"
        do_scroll_x: False
        scroll_type: ['bars', 'content']

        RecycleGridLayout:
            cols: 2
            default_size: None, None
            default_size_hint: 1, None
            size_hint: 1, None
            height: self.minimum_height
            padding: [dp(16), dp(16), dp(16), dp(16)]
            spacing: dp(20)

<MyColor@CAnchorLayout>:
    anchor_x: 'center'
    anchor_y: 'center'
    size_hint: 1, 1
    token: ""
    padding: dp(16)

    CLabel:
        text: root.token
        padding: dp(4)
        bg_color: [1, 1, 1, 0.6]
        color: app.text_primary
"""

from kivy.lang import Builder
from kivy.uix.recycleview import RecycleView

from carbonkivy.theme.color_tokens import thematic_tokens, static_tokens
from carbonkivy.app import CarbonApp
from carbonkivy.uix.screen import CScreen


class ColorView(RecycleView):
    def __init__(self, **kwargs):
        super().__init__(**kwargs)
        self.app = CarbonApp.get_running_app()
        self.data = []
        tokenl = {}
        tokenl.update(thematic_tokens)
        tokenl.update(static_tokens)
        for token in tokenl.keys():
            if hasattr(self.app, token):
                self.data.extend([
                    {
                        "bg_color": getattr(self.app, token),
                        "token": token,
                    }
                ])


class myapp(CarbonApp):
    def __init__(self, *args, **kwargs):
        super(myapp, self).__init__(*args, **kwargs)

    def build(self) -> CScreen:
        screen = Builder.load_string(appkv)
        return screen


if __name__ == "__main__":
    myapp().run()

Thematic tokens

These tokens are expected to attain different color values based on the current color theme of the app.

See also

ThematicColors

Static tokens

These tokens are expected to attain a fixed color value on start.

See also

StaticColors

Usage

All available color tokens can be accessed via the main app class.

kvlang

CScreen:
    bg_color: app.interactive

python

...

class MyApp(CarbonApp):

    def build(self) -> CScreen:
        self.screen = CScreen(bg_color=self.interactive)
        return self.screen

...

These tokens can also be used directly in the application but you’ll need to bind an update to all the thematic_tokens inside the on_theme method based on the current color theme of your app.

from kivy.properties import ColorProperty

from carbonkivy.app import CarbonApp
from carbonkivy.uix.color_tokens import thematic_tokens, static_tokens

class MyApp(CarbonApp):

    mycolor = ColorProperty()

    def __init__(self, **kwargs) -> None:
        super(MyApp, self).__init__(**kwargs)
        self.mycolor = thematic_tokens["interactive"][self.theme]

    def on_theme(self, *args) -> None:
        super(MyApp, self).on_theme(*args)
        self.my_color = thematic_tokens["interactive"][self.theme]

...

All available color tokens are a part of the colormap utility, so they can also be used as normal strings.
Note

Using these tokens as strings attains color values based on the color theme of the app on start. These color values will not update with a change in the color theme.
CScreen: bg_color: "interactive" # attains a fixed color value on start.
